TEV Maori, profile showing proposed after mast with lights rearranged to suit

Descriptive Data

Record Identifier67Date Range1965DescriptionTaikoo Dockyard and Engineering Company. Drawing No. 12071. Note: annotations at top left "541/1976", "Enclosed with letter dated 18.6.65" at top right, and on plan itself "existing forward masthead light support tube", "cut from original No 4 derrick tube (11% reduced to 9 1/2% at 'xx'), "New 10"% struts", "Existing "5% tubes", "Topmast of sufficient height to allow House flag to fly clear of obstructions if required", "aerial halyard block", "section of existing 'cross-bar' tube between heads of forward derrick bosts (14 3/4"%)". "240/377" on rear.
MediumPlan
