TEV Maori, arrangement of mast head lights

Descriptive Data

Record Identifier65Date Range1965DescriptionTaikoo Dockyard and Engineering Company. Drawing No. 12032. Scale: 1/8 inch = 1 foot. Note: annotations on plan, "Possibility that mast lights may be retained in existing position", the word 'guard' corrected to 'guide', "mast should be located as far forward (within deckhouse) as possible with lights at minimum height determined by height of lights in existing position on main mast", "Spare No. 1 derrick could be utilised for mast tube with plates added and existing tube support welded on top to make up the necessary height", "Approximate end of derrick when stepped on deck", annotation at bottom right "Enclosed with letter dated 28 May 1965", annotation on read "240 376".MediumPlan

Access Information

Restriction StatusOpen
