TEV Maori, sample cabin, 4 berth

Descriptive Data

Record Identifier6Date Range1951DescriptionScale 3/4 inch = 1 foot. Plan number 223. Ship number 139. Note: annotation on top drawing "'Hinemoa' 2'-10 1/2" to underside of plywood board at top level (per VGW), annotation at left of page "12" requested at side of door for stowage of level ladder", annotation at bottom right "Letter tracing of print sent by D.C. 27/8/51 Original returned to V.G.W.". Verso - annotation at bottom left "Maori No 14 x 3".MediumPlan

Access Information

Restriction StatusOpen
